Application and Development of Laser Cleaning Technology in the Wood Products Industry

As the global manufacturing industry places increasingly stringent demands on environmental protection, efficiency and precision, laser cleaning—an innovative non-contact, pollution-free and high-precision surface treatment technology—is ushering in a green revolution for the traditional wood products industry. Studies have shown that precise control of laser parameters (e.g., wavelength, power, pulse width) enables the effective removal of contaminants such as paint, glue, stains and mold from wood surfaces without damaging the wood substrate. This technology is particularly suitable for the restoration of exquisite wood veneers, complex carved components and cultural relics. Additionally, laser surface treatment can be applied to wood surfaces to alter their color, improve surface wettability, enhance the performance of surface coating materials, and boost anti-corrosion and anti-mold properties. Looking ahead, with the integration of intelligent technologies such as beam shaping, adaptive focusing and real-time monitoring, coupled with the gradual reduction in equipment costs, laser cleaning technology is expected to play an increasingly important role in high-end furniture manufacturing, ancient building restoration and wood product remanufacturing, emerging as a key driving force fo the industry's transformation and upgrading toward intellectualization and green development.

Application of Laser Cleaning in the Restoration of Wood Carvings

Laser Cleaning vs. Traditional Cleaning

Limitations of Traditional Wood Cleaning

The wood products industry spans a wide range of sectors, from furniture manufacturing and architectural decoration to craft carving, where surface cleaning is a critical step in the production process. Conventional cleaning methods, including mechanical grinding, chemical solvent cleaning and high-pressure water washing, are plagued by numerous limitations. Most of these methods require consumables (e.g., abrasives, chemical reagents), generate secondary waste and increase disposal costs. Furthermore, they are difficult to automate, involve high labor intensity and fail to ensure consistent cleaning quality. As an emerging surface treatment technology, laser cleaning offers a brand-new technical solution to these pain points in the wood products industry with its unique advantages. A laser cleaning machine irradiates the wood surface with high-energy pulsed laser, causing stains, paint or oxide layers to vaporize or peel off instantaneously without damaging the substrate.

Core Advantages of Laser Cleaning

1. Precise control: The spot diameter can be adjusted to 0.1-5 mm, suitable for the local treatment of wood with complex textures.

2. Environmental friendliness: No chemical solvents are used, reducing VOC emissions and complying with the EU REACH environmental standards.

3. High efficiency: Experiments show that it only takes 3-5 minutes to remove old paint from 1 square meter of wood, representing a 50% efficiency improvement over mechanical grinding.

Mechanism of Laser Cleaning

Photothermal Effect (Ablation)：When contaminants absorb the high-energy laser beam, their temperature rises sharply in an extremely short time (nanosecond or even picosecond level) to exceed their vaporization or boiling point, leading to instantaneous evaporation or thermal expansion and subsequent peeling from the substrate surface in the form of shock waves. This mechanism is particularly effective for removing paint, residual glue and heavy dirt from wood surfaces.

Photochemical Effect：For certain specific contaminants, short-wavelength lasers such as ultraviolet (UV) lasers deliver high single-photon energy that can directly break the chemical bonds of contaminants, decomposing them into volatile small molecules to achieve non-thermodynamic "cold" peeling. This method results in an extremely small heat-affected zone, making it ideal for the treatment of heat-sensitive wood surfaces and precious cultural relics.

Key Processes of Wood Laser Cleaning: Customized Non-Destructive Cleaning

The cleaning effect of laser technology is not determined by a single factor but by the synergistic effect of a series of parameters including wavelength, power, pulse duration and scanning speed. Selecting the optimal combination of parameters for wood products is the core technical challenge to achieving efficient and non-destructive cleaning, and the choice of laser determines the wavelength used.

Nd:YAG laser (1064 nm): Currently the most widely used type, it exhibits good absorption for various contaminants such as paint, rust and oil stains, and has relatively shallow penetration into wood. It has been proven effective for the cleaning of fine materials including wood.

CO₂ laser: Wood has an extremely high absorption rate for this wavelength, which is mainly used for wood cutting and carving. Extreme caution is required in cleaning applications, as it can easily cause substrate ablation.

Ultraviolet (UV) laser: Realizes "cold processing" through the photochemical effect with minimal thermal impact. Theoretically, it is highly suitable for the treatment of extremely precious and heat-sensitive wooden cultural relics, but the equipment cost is relatively higher.

Power and energy density: Excessively high energy density can cause carbonization, discoloration and even combustion of the wood surface. Studies have clearly indicated that when using a 1064 nm laser to clean wood products, the energy density should be strictly controlled below 1.5 J/cm² to avoid microscopic damage to the wood.

Pulse duration: The shorter the pulse duration (e.g., nanosecond, picosecond), the more concentrated the laser energy acts on the surface, and the less obvious the heat diffusion effect into the substrate, i.e., the smaller the heat-affected zone. For heat-sensitive wood, the use of short or ultra-short pulse lasers is the key to achieving precise and non-destructive cleaning.

Scanning speed and repetition rate: These two parameters jointly determine the cleaning efficiency and heat accumulation effect. Excessively slow scanning speed or too high repetition rate can cause repeated laser irradiation on the same spot, easily leading to wood burning; on the contrary, insufficient cleaning may occur.

Main Applications of Laser Cleaning in the Wood Products Industry: Enormous Application Potential

With its technical advantages, laser cleaning demonstrates tremendous application potential in multiple sub-sectors of the wood products industry, including the following scenarios:

1. High-end furniture manufacturing and remanufacturing：In furniture production, it can be used to accurately remove excess glue overflowing after board edge banding, pre-process the edges of MDF boards to enhance coating adhesion, or strip old paint from used furniture for renovation. Its non-destructive property protects high-value wood substrates.Lasers can remove impurities such as resin and mold from wood surfaces to improve the adhesion of subsequent coatings. For example, the paint adhesion test results of pine wood have been improved from Grade 2 to Grade 4 (ASTM D3359 standard) after laser treatment.

2. Ancient building and wooden cultural relic restoration：This is one of the most valuable application fields of laser cleaning technology. For wood carvings and decorative moldings with complex concave-convex textures, traditional tools are difficult to reach and easily cause damage, while lasers can remove oxide layers layer by layer without damaging the original wood grain.A case study by the Fraunhofer Institute in Germany shows that a 20W fiber laser can remove 90% of mold from pine wood surfaces at a speed of 0.1 mm/s, while oak wood requires an upgrade to 40W due to its higher density. The cleaning depth error of 1064 nm laser on oak wood is less than 0.05 mm.

3. Wooden mold cleaning：In processes such as wood hot press forming, resin and adhesive residues accumulate on mold surfaces. Laser cleaning can clean molds quickly and efficiently, improving production efficiency and product quality.

Emerging Technological Trends and Industry Prospects

1. Cost reduction and market popularization: With the maturation of fiber laser technology and the increase in localization rate, the cost of laser cleaning equipment is decreasing year by year. It is expected that in the next 3-5 years, its price will become more affordable, making it accessible to small and medium-sized wood product enterprises and thus driving its popularization in the industry.

2. AI + Laser Cleaning: Artificial intelligence and machine learning algorithms will be introduced into the parameter optimization process. By training on a large amount of cleaning data for different wood types and contaminants, the system will be able to automatically recommend or directly set the optimal process parameters, greatly reducing the reliance on the operator's experience and making the technology more user-friendly.

3. Expansion of application fields: Laser technology may also be combined with wood modification, such as improving the hydrophilicity or hydrophobicity of wood surfaces through low-energy laser irradiation to enhance their functionality.

Laser cleaning technology is standing at a crossroads of transformation for the wood products industry. It is not only a cleaner, more efficient and precise surface treatment tool, but also a green manufacturing paradigm that aligns with the concept of sustainable development in the future. With the continuous maturation of technology and the improvement of intellectualization, laser cleaning will first achieve breakthroughs in high-value-added fields such as high-end furniture manufacturing, cultural relic and building restoration, and precision woodworking, and gradually penetrate into a wider range of wood product processing sectors.
